12-Inch Longworth Wood Lathe Chuck, Self-Centering with 1-Inch - 8TPI Thread Lathe Chuck

Brand: PHUKIMLONG

Features:

• 12 Inch Self-Centering with 1 Inch-8TPI Thread Longworth Wood Lathe Chuck.
• Capacity in expansion mode: 4'' to 11-4/5'' in diameter.
• Capacity in compression mode: 2-3/5'' to 9-4/5'' in diameter.
• Threads Directly Onto Lathe Spindle 1x8 Faceplate Included.
• Buttons close in concentrically, making it easy to center your project.

model number: LW12

Part Number: LW12

Details: Re-chucking bowls and patters for finishing or light shaping has always been something woodturners want to solve.The longworth wood lathe chuck makes it easy. This self-centering scroll operation quickly adjusts to fit the work and tightening only takes a few seconds. Designed for clamping in a traditional 4 jaw-self-centering wood lathe chuck using standard 50mm dovetail jaws. It eliminates the time and hasse of removing and remounting chuck jaws needed when using regular re-chucking jaws. Non-Marking premium silicone grippers provide pliable yet firm gripping power Precision cut, plates provide ultimate performance and reliability 600 RPM maximum. Chuck size indicates the minimum lathe swing for which it is intended Maximum external gripping capacity is approximately 2" smaller than chuck diameter.
Products Inculdes:
1 Ea* 12 Inch Longworth Wood Lathe Chuck
6 Each Gripper Buttons : 0.78 Inch
6 Each Gripper Buttons : 1.57 Inch

Package Dimensions: 14.5 x 14.4 x 3.9 inches
