Cloudray CO2 Laser Lens 15mm Laser Mirror CO2 Laser Focal Lens CO2 Focus Lens,CVD ZnSe for CO2 Laser Engraving Cutting Machine,Laser Cutter
Availability & Shipping
Availability & Shipping
- Product availability: This is a US based website and some products may not be available outside the US.
- Shipping info: The majority of items have free shipping, but some products due to size or shipping location may have a shipping fee.
- Our Supporting Artisans who helped curate the products on this site will share commissions for purchases made through links in this post.
Transparency
Transparency
- Transparency: Unfortunately due to high levels of fraud committed on this shop our team has decided to only work with trusted suppliers to bring you the high quality items and fast shipping you've been used to from now on.
🔥 Newsletter 🔥
Sign up for exclusive offers, new items, and more.
Description
Description
Brand: Cloudray
Color: Diameter 15mm(0.59 Inch)
Features:
- Material: High Quality CVD Znse,compatible power: 40W-200W
- Diameter: 15mm/0.59"; Focal Length:50.8mm/2"; Thickness: 2mm/0.07"
- Shape: Meniscus; Transmittance: ≥99.5%;Package includes: 1 x Lens
- Superb Coating Process: Double-sided Solid Coating. Wiping Resistance. Long Working Life
- Usage: CO2 Laser Lens for CO7 laser engraving, cutting machine
model number: USA CVD
Part Number: 15-50.8
Details:
Feature:
CVD ZnSe Imported From USA, High Quality Material Make Sure the Steady of Laser System.
The CO2 Laser Transmittance of Lens can is more than 99.5% with Excellent Transparency.
Excellent High-Power Density Endurance.
Firm Surface Membrane. High Durabilityand Great Scratch Resistance.
Focusing Spot Size more Smaller.
Note: In general,a laser machine needs 1 pies of focusing lens and 3 reflective mirrors.
CO2 Laser Mirrors Purchase ASIN: B07B8YZLCP or B07BJHL3Y4
CO2 Laser Head Purchase ASIN: B07BGTWRY1
Specification:
Material:USA CVD ZnSe
Wavelength:10.6um
Transmittance:99.5%
Clear Aperture>90%
AR/AR coating R<0.5% per surface
Diameter tolerance:+0/-0.1mm
Thickness tolerance:+0/+0.2mm
FL Tolerance<±2%
Surface Figure<λ/2 per 1"Dia
Surface Quality 40-20scratch and dig
The difference between USA ZnSe and China PVD:
The China ZnSe can withstand less than 100W Laser power. While USA material can withstand higher power up to 200W.
And USA ZnSe has better focusing spot and better laser transmittance than China matierial.
Packing List:
Focus Lens USA x1pcs
EAN: 0661021764922
Package Dimensions: 5.1 x 3.5 x 3.1 inches
