Industrial Chiller, 110V CW-5200 Industrial Water Chiller, 9L Capacity Cooling Water,0.15A-2.3A Current Recirculating Chiller for 50W to130W
Availability & Shipping
Availability & Shipping
- Product availability: This is a US based website and some products may not be available outside the US.
- Shipping info: The majority of items have free shipping, but some products due to size or shipping location may have a shipping fee.
- Our Supporting Artisans who helped curate the products on this site will share commissions for purchases made through links in this post.
Transparency
Transparency
- Transparency: Unfortunately due to high levels of fraud committed on this shop our team has decided to only work with trusted suppliers to bring you the high quality items and fast shipping you've been used to from now on.
🔥 Newsletter 🔥
Sign up for exclusive offers, new items, and more.
Description
Description
Brand: SDKEHUI
Features:
- 9L cooling tank capacity - The water cooler provides stable performance with a large capacity 9L cooling box. Equipped with precision scale, you can fill water according to the scale.
- Dual Cooling Fans - Professional forced air cooled radiators inside quickly dissipate heat. High heat dissipation capacity means that the water cooler is not easily blocked.
- Precise Thermostat - This CNC machine industrial cooler is equipped with a precise temperature controller. You can accurately set and monitor the real-time temperature to ensure the working status of the machine.
- Multiple alarm functions - This water cooler with laser engraver has various protection and early warning functions, water flow alarm protection, high/low temperature alarm, compressor delay protection, and compressor overcurrent protection. These measures can protect the machine from overheating and extend its service life.
- User-friendly handle - Rubber handles are super durable and reliable. Ergonomic design makes it very comfortable to hold, saves time and effort, and improves working efficiency.
- Wide application - CW-5200 series is a professional cooling machine, easy to install and operate, compact and easy to move. It is designed for cooling the one CO2 glass tube under 50W / 60W / 80W / 100W / 130W of laser engraving and cutting machine.
model number: CW5200
Part Number: KHH99SLJ5200101V-US-SD
Details: Description:
CW-5200 series is a professional water chiller designed according to the international advanced pyrolysis cooling system. It is suitable for machines which are required for small water-cooled cooling equipment. It has a cooling tank of 9L with full water flow and over temperature alarm functions. The built-in fan for effective ventilation provides effective ventilation and high capacity of heat dissipation. It is designed to cool CO2 glass tube in laser engraving and cutting machine to 50W 60W 80W 100W 130W.
Specifications:
Model: CW-5200
Voltage: 110V
Frequency: 60HZ
Current: 0.15A-2.3A
Tank capacity: 9L
Compressor power: 200W
Cooling capacity: 2866Btu/h, 0.84KW, 722Kcal/h
Refrigerant: R-134a
Refrigerant charge: 9.9oz / 280g
Accuracy of temperature control: ±2℃.
Reducer: capillary
Pump capacity: 60W
Maximum flow rate: 10L/min
Maximum pumping stroke: 8.7 yards / 8M
Inlet and outlet: external 0.4 inch / 10 mm brass connection
Protection: Over current protection for compressor, flow alarm, over temperature alarm
Packing
1.1x industrial cooling unit.
2.1x Copy user manual.
3.1xPC power cord.
4.1xPC alarm signal output connector.
5.1xPC spare fuse.
(Heroine refused to use a power outlet).
